5Kg Load Cell Weight Sensor

80.00 EGP

Add to Wishlist
Add to Wishlist
Category:

Description

Description

Rated Load: 5Kg
Rated Output: 1.0 to positive and negative 0.1mV or V
Nonlinear: 0.03 percent F.S
Hysteresis: 0.03 percent F.S
Repeatability: 0.03 percent F.S
Creep(5 minutes): 0.05 percent F.S
Output temperature: 0.003 percent F.S or degree celsius
Zero temperature: 0.02 percent F.S or degree celsius
Zero balance: positive and negative 0.1000 mV or V
Input impedance: 1066 positive and negative 20 percent ohm
Output impedance: 1000 positive and negative 10 percent ohm
Insulation Resistance: 2000 Megohms
Operating temperature range: minus 20 to 65 degree celsius
Recommended operating voltage: 5 VDC
Maximum operating voltage: 10 VDC
Protection class: IP65
Material: Aluminum Alloy
Size: 75 x 13 x 13mm or 2.95 x 0.51 x 0.51 inch
Weight: 30g

Connections

Red to E+
Black to E-
Green to A+
White to A-

Output Instructions:
The sensor output is an analog voltage and the voltage value is determined by the excitation voltage (working voltage).
For example: if the excitation voltage is DC5V, the full-scale output voltage value of the pressure sensor is: 5V*1.0mv/v=5mV;
That is, the signal voltage output range is 0-5mV, and the greater the applied pressure, the greater the corresponding output voltage value.
