Name: Arduino MEGA 2560 CH340
SKU: 22623
Availability: InStock

Arduino MEGA 2560 CH340

1.250,00EGP

Arduino MEGA 2560 CH340 Microcontroller: ATmega2560 Operating Voltage: 5VDC Input Voltage (recommended): 7-12V through DC jack Input Voltage (limits): 6-20V through DC jack Digital I/O Pins: 54 (of which 14 provide PWM output) Analog Input Pins: 16 DC Current per I/O Pin: 40 mA DC Current for 3.3V Pin: 50 mA Flash Memory: 256 KB of which 8 KB used by the bootloader SRAM: 8 KB EEPROM: 4 KB Clock Speed: 16 MHz CH340 as USB to UART IC USB B type socket for USB power and interface

In stock

SKU: 22623

Category: Arduino Boards

Description

Arduino MEGA 2560 CH340

The Arduino Mega 2560 is a microcontroller board based on the ATmega2560. It has 54 digital input/output pins (of which 15 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Mega 2560 board is compatible with most shields designed for the Uno and the former boards Duemilanove or Diecimila.

Specifications:

Microcontroller	ATmega2560
Operating Voltage	5V
Input Voltage (recommended)	7-12V
Input Voltage (limit)	6-20V
Digital I/O Pins	54 (of which 15 provide PWM output)
Analog Input Pins	16
DC Current per I/O Pin	20 mA
DC Current for 3.3V Pin	50 mA
Flash Memory	256 KB of which 8 KB used by bootloader
SRAM	8 KB
EEPROM	4 KB
Clock Speed	16 MHz
LED_BUILTIN	13
Length	101.52 mm
Width	53.3 mm
Weight	37 g
