FC-10 Female IDC Connector with Strain Relief, 2.54mm Pitch

FC-10 Female IDC Connector with Strain Relief

SKU: 25368
shield

Safe shopping

Your data is always protected

Sale_coupon_15

3,50EGP

In stock

In stock

15 People watching this product now!
  • shop Pick up from the Store

Everyday from 9 AM to 7 PM

  • aramex ARAMEX DELIVREY

2-3 Days

Total fees when checkout

  • product-return Return within 14 days

Payment Methods:

Description

FC-10 Female IDC Connector with Strain Relief

  • Strong polyester housing
  • Central Bump Polarization
  • Operating temperature from -45°C to +105°C
  • Supports a 1.27mm cable pitch

Specifications:

Attribute Value
Number of Contacts 10
Number of Rows 2
Gender Female
Pitch 2.54mm
Mounting Type Cable Mount
Body Orientation Right Angle
Termination Method IDC
Current Rating 1A
Contact Plating Gold over Nickel
Minimum Operating Temperature -55.0°C
Maximum Operating Temperature 105.0°C
Housing Material PBT
Contact Material Phosphor Bronze

Package Includes:

  • 1x 10 Pin IDC Cable Connector
