HC-SR312 PIR Motion Sensor Module

The HC-SR312 human body induction module is a digital intelligent automatic control product based on passive human body infrared technology, with high sensitivity and reliability. It is widely used in all kinds of automatic induction electrical equipment.

Features:

• Low power consumption, small size, easy for embedded installation
• Internal digital signal processing, anti-interference enhancement
• High sensitivity and high reliability, can be widely used in automatic sensing circuit technical parameters
• Anti-interference enhancement, internal use of digital signal processing, direct high and low level output
• Repeatable trigger mode: after induction output high level, the time delay period, if there is the human body in the scope of its induction activities, its output will always keep a high level, until the people left after the delay, it becomes low level (that is, the sensing module automatically delays a delay period after detecting each activity of the human body, and takes the time of the last activity as the starting point of the delay time)

Specification:

• Working Voltage: DC 2.7-12V
• Static Power Consumption: <0.1mA
• Delay Time: 2 seconds
• Blocking Time: 2 seconds
• Trigger Mode: repeatable
• Sensing Range: ≤100 degree cone angle, 3-5 meters (depending on the specific lens)
• Working Temperature: -20 – +60°C
• PCB Dimensions: 10mm x 8mm

Package Includes:

• 1x HC-SR312 PIR Motion Sensor Module

Datasheet:

• HC-SR312
