Transformer 5A (220Vac TO 20-0-20Vac)

Transformer 5A (220Vac TO 20-0-20Vac)

  • Step-down Centre tapped
  • Input Voltage: 220V AC at 50Hz
  • Output Voltage: 20-0-20Vac
  • Output Current: 5A
  • Vertical mount type
  • Low cost and small package
SKU: 26667
shield

Safe shopping

Your data is always protected

Sale_coupon_15

265,00EGP

In stock

In stock

11 People watching this product now!
  • shop Pick up from the Store

Everyday from 9 AM to 7 PM

  • aramex ARAMEX DELIVREY

2-3 Days

Total fees when checkout

  • product-return Return within 14 days

Payment Methods:

Description

Transformer 5A (220Vac TO 20-0-20Vac)

A center-tapped transformer also known as two phase three wire transformer is normally used for rectifier circuits. When a digital project has to work with AC mains a Transformer is used to step-down the voltage and then convert it to DC by using a rectifier circuit. In a center-tapped transformer the peak inverse voltage is twice as in bridge rectifier hence this transformer is commonly used in full wave rectifier circuits.

Specifications:

  • Step-down Centre tapped
  • Input Voltage: 220V AC at 50Hz
  • Output Voltage: 20-0-20Vac
  • Output Current: 5A
  • Vertical mount type
  • Low cost and small package

Applications:

  • Rectifier circuits
  • AC-AC step down
  • Full wave rectifiers

Datasheet:
