ACS712 Current Sensor Module – 30A

ACS712 Current Sensor Module – 30A

  • 80kHz bandwidth
  • 66 to 185 mV/A output sensitivity
  • Low-noise analog signal path
  • Device bandwidth is set via the new FILTER pin
  • 1.2 m? internal conductor resistance
  • Total output error of 1.5% at TA = 25?C
  • Stable output offset voltage.
  • Near zero magnetic hysteresis
SKU: 24329
shield

Safe shopping

Your data is always protected

Sale_coupon_15

120,00EGP

In stock

In stock

15 People watching this product now!
  • shop Pick up from the Store

Everyday from 9 AM to 7 PM

  • aramex ARAMEX DELIVREY

2-3 Days

Total fees when checkout

  • product-return Return within 14 days

Payment Methods:

Description

ACS712 Current Sensor Module – 30A

The ACS712 is a fully integrated, hall effect-based linear current sensor with 2.1kVRMS voltage isolation and a integrated low-resistance current conductor. Technical terms aside, it?s simply put forth as a current sensor that uses its conductor to calculate and measure the amount of current applied.

  • 80kHz bandwidth
  • 66 to 185 mV/A output sensitivity
  • Low-noise analog signal path
  • Device bandwidth is set via the new FILTER pin
  • 1.2 m? internal conductor resistance
  • Total output error of 1.5% at TA = 25?C
  • Stable output offset voltage.
  • Near zero magnetic hysteresis

applications:

  • Motor speed control in motor control circuits
  • Electrical load detection and management
  • Switched-mode power supplies (SMPS)
  • Protection for over-current

2D Model and Dimensions:

ACS712 Current Sensor Dimensions

Package Includes:

  • 1x ACS712 module
Product Datasheet:
