HLK-20M12 AC-DC Module 220vac to 12VDC 20W HI LINK
| Environmental conditions | |||
| Operating temperature | -25~+60 | ℃ | |
| Storage temperature | -40~+85 | ℃ | |
| relative humidity | 5-95 | % | |
| Heat dissipation | Natural cooling | ||
| atmospheric pressure | 80-106 | Kpa | |
| altitude | ≤2000 | m | |
| vibration | 振动系数10~500Hz,2G10min./1cycle,60min.each along X,Y,Z axes | Meet the requirements of secondary road transportation | |
| Electrical characteristics |
|||
| Rated input voltage | 100~240 | Vac | |
| Input voltage range | 85~264 | Vac | or 120~350Vdc |
| Maximum input current | ≤0.4 | A | |
| Enter the inrush current | ≤34 | A | typical |
| Enter Soft Start | ≤50 | mS | |
| Long-term reliability | MTBF≥100,000 | h | |
| External fuses are recommended | 2A/250Vac | Slow fuse | |
| Output characteristics | |||
| Output load | Load percentage 100%MAX | ||
| Voltage regulation | ±0.2 | % | TPY |
| Load regulation | ±0.5 | % | TPY |
| Output overcurrent protection | 110~150 | % | Maximum load |
| Output short-circuit protection | Sustainable, self-healing | Do not damage the whole machine | |
| Ripple & Noise | ≤150 | mVp-p | Ripple noise test: rated input voltage, output full load. Tested with a 20MHz bandwidth oscilloscope, load side and 10uF and 0.1uF capacitors. |
