TP5100 Lithium Battery Charger Module Single/Double Cell 2A
TP5100 Lithium Battery Charger Module Single/Double Cell 2A
- Dual/single Lithium battery charger
- Programmable charging current up to 2A
- Temperature, overcurrent and undervoltage protection
- Trickle, constant current and constant voltage charging
Safe shopping
Your data is always protected
Sale_coupon_15
55,00EGP
In stock
In stock
10
People watching this product now!
-
Pick up from the Store
Everyday from 9 AM to 7 PM
-
ARAMEX DELIVREY
2-3 Days
Total fees when checkout
-
Return within 14 days
Payment Methods:
Description
TP5100 Lithium Battery Charger Module Single/Double Cell 2A
The TP5100 is an integrated Lithium battery charger that has a switch mode buck topology. It has all the integrated functions to charge a single or dual cell Lithium battery, along with a few peripheral components
Pin Configuration:
- VIN+: Input voltage pin (20V max.)
- GND: Input ground reference
- BAT+: Battery positive output
- GND: Battery negative
- CHARGING: LED output to indicate charging
- GND: LED ground reference
- CHARGED: LED output to indicate battery charged
Features:
- Dual/single Lithium battery charger
- Programmable charging current up to 2A
- Temperature, overcurrent and undervoltage protection
- Trickle, constant current and constant voltage charging
Package includes:
- 1x TP5100 Charger Module
Datasheet:
